Colt · Bafang 500W Hub · 48V 20Ah · Shimano Alivio 9-Speed · 27.5"
Surface 604 Colt
The biggest battery in the commuter class — 960 Wh, up to 150 km range, torque-sensing pedal assist, and Class 3 speed. UL dual-certified, designed in Vancouver.
The Surface 604 Colt is a purpose-built commuter e-bike carrying the largest battery capacity in its class. The 48V 20Ah (960 Wh) Samsung 21700 lithium-ion pack delivers up to 150 km of eco-mode range — enough for multi-day use between charges. A Bafang geared hub motor provides 65 Nm of torque through a dropout torque sensor, so assist power scales naturally with rider input rather than just pedal speed. Class 3 certified at 45 km/h PAS, with an additional thumb throttle for up to 32 km/h on demand. Shimano Alivio 9-speed drivetrain, Tektro Auriga hydraulic disc brakes, SR Suntour suspension fork, and a rear rack standard. UL 2271 (battery) and UL 2849 (complete bike) dual-certified.
Highlights
960 Wh — class-leading battery capacity
31% more capacity than Aventon, 43% more than Lectric. The Samsung 21700 cell pack is rated up to 150 km eco range — one charge covers a full week of daily commuting without ever thinking about plugging in.
Dropout torque sensor — natural pedal feel
Surface 604's dropout torque sensor measures actual pedalling force at the dropout — not cadence-only. Assist ramps up and down proportionally to how hard you push, giving a much more bike-like riding experience than cadence-only systems.
Class 3 — 45 km/h PAS
Assists up to 45 km/h under pedal assist — fast enough to keep up with urban traffic on arterials. Thumb throttle provides up to 32 km/h for rolling starts and slow-traffic gaps without pedalling.
UL 2271 + UL 2849 dual certified
UL 2271 tests the battery pack independently; UL 2849 tests the full electrical system — motor, battery, controller, wiring — as a complete bike. Both certifications are required by many insurers and multi-unit buildings.
Tektro Auriga hydraulic disc brakes
180mm rotors front and rear, post-mount. Hydraulic self-adjusting — consistent stopping power fully loaded without manual pad adjustment. Motor inhibitors cut assist the moment you touch the lever for immediate response.
Commuter-ready from box — rack, lights, kickstand standard
Welded rear rack, Büchel 150-lumen front and rear LED lights, and heavy-duty adjustable kickstand all included. No accessories required to start commuting — assembly takes approximately 20 minutes.
Colours
Powertrain
| Motor | Bafang 500W (peaks 750W) Geared Hub Brushless |
| Torque | 65 Nm |
| Drive mode | Dropout torque-sensing pedal assist + thumb throttle |
| Throttle | Thumb push-activated |
| Controller | Surface 604 custom 12 MOS 48V 500W 25Ah Smart Controller |
| Top speed (PAS) | 45 km/h (28 mph) · Class 3 |
| Top speed (throttle) | 32 km/h (20 mph) |
Battery & Range
| Battery | 48V 20Ah / 960 Wh — Samsung lithium-ion 21700 cells |
| Battery weight | 4.65 kg / 10 lbs |
| Certification | UL 2271 (battery) + UL 2849 (complete system) |
| Range | Up to 150 km / 90 mi (eco mode) |
| Charge time | 3–4 hours (full charge from empty) |
Electronics
| Display | Surface 604 colour LCD, 3.5", with USB charging jack |
| Front light | Büchel "Secu Forte" LED — 150 lumens |
| Rear light | Büchel LED rear light |
| Wire harness | 30Ah rated, handles up to 120A (upgraded) |
Drivetrain
| Derailleur | Shimano Alivio 9-speed |
| Cassette | Shimano 11–36T |
| Shift levers | Shimano Alivio |
| Chain | KMC 9-speed |
| Crankset | Samox 42T front sprocket |
| Bottom bracket | Samox sealed |
Brakes
| Brakes | Tektro Auriga hydraulic disc — post mount, with motor inhibitors |
| Rotors | 180mm front and rear · 2.34mm thick |
Suspension
| Fork | SR Suntour XCM 27.5 · 80mm travel · quick release |
| Rear | Hardtail — no rear suspension |
Wheels & Tires
| Wheel size | 27.5" |
| Tires | 27.5" × 2.4" Panaracer · puncture protection · reflective sidewall |
| Rims | Aluminum alloy double-wall · 27.5" · 13G · 36H |
| Front hubs | Surface 604 aluminum |
Frame & Cockpit
| Frame | 6061 aluminum alloy · straight steerer headtube · custom reinforced battery mounts · internal cable routing · post-mount brakes |
| Stem | Satori Up2 adjustable |
| Handlebar | Promax aluminum · 30mm rise · 15° backsweep · 700mm wide |
| Pedals | Wellgo platform die-cast |
| Saddle | Selle Royal "Essenza Plus" gel · elastomer · relaxed position · 9° adjustable |
| Seat post | 30.4mm |
| Kickstand | Adjustable heavy-duty aluminum |
Sizing
| Sizes | S/M · M/L |
| Frame size (S/M) | 17.5" · for riders 5'2"–5'7" (158–170 cm) |
| Frame size (M/L) | 19.5" · for riders 5'8"–6'6" (173–198 cm) |
| Standover (S/M) | 28.5" / 724 mm |
| Standover (M/L) | 30" / 762 mm |
| Weight capacity | 136 kg / 300 lbs |
Weight & Features
| Net weight | 27.75 kg / 61 lbs (with 20Ah battery) |
| Standard accessories | Welded rear rack · adjustable kickstand · chain guide · water bottle bosses · fenders |
| Lights | Integrated front + rear (standard) |
| Optional upgrade | SR Suntour NCX suspension seatpost |
| Assembly time | ~20 minutes |
| Warranty | 5-year frame · 2-year components |
| Origin | Designed in Vancouver, Canada |
Surface 604 Colt · 48V 20Ah / 960 Wh · Bafang 500W · Shimano Alivio 9-Speed · 27.5" · S/M / M/L
- Description
Colt · Bafang 500W Hub · 48V 20Ah · Shimano Alivio 9-Speed · 27.5"
Surface 604 Colt
The biggest battery in the commuter class — 960 Wh, up to 150 km range, torque-sensing pedal assist, and Class 3 speed. UL dual-certified, designed in Vancouver.
$2,599.00 CAD · 20Ah only960 Wh battery capacity 45 km/h Class 3 PAS speed 27.75 kg total weight Up to 150 km — eco range · 48V 20Ah battery range · eco mode
The Surface 604 Colt is a purpose-built commuter e-bike carrying the largest battery capacity in its class. The 48V 20Ah (960 Wh) Samsung 21700 lithium-ion pack delivers up to 150 km of eco-mode range — enough for multi-day use between charges. A Bafang geared hub motor provides 65 Nm of torque through a dropout torque sensor, so assist power scales naturally with rider input rather than just pedal speed. Class 3 certified at 45 km/h PAS, with an additional thumb throttle for up to 32 km/h on demand. Shimano Alivio 9-speed drivetrain, Tektro Auriga hydraulic disc brakes, SR Suntour suspension fork, and a rear rack standard. UL 2271 (battery) and UL 2849 (complete bike) dual-certified.
Highlights
960 Wh — class-leading battery capacity
31% more capacity than Aventon, 43% more than Lectric. The Samsung 21700 cell pack is rated up to 150 km eco range — one charge covers a full week of daily commuting without ever thinking about plugging in.
Dropout torque sensor — natural pedal feel
Surface 604's dropout torque sensor measures actual pedalling force at the dropout — not cadence-only. Assist ramps up and down proportionally to how hard you push, giving a much more bike-like riding experience than cadence-only systems.
Class 3 — 45 km/h PAS
Assists up to 45 km/h under pedal assist — fast enough to keep up with urban traffic on arterials. Thumb throttle provides up to 32 km/h for rolling starts and slow-traffic gaps without pedalling.
UL 2271 + UL 2849 dual certified
UL 2271 tests the battery pack independently; UL 2849 tests the full electrical system — motor, battery, controller, wiring — as a complete bike. Both certifications are required by many insurers and multi-unit buildings.
Tektro Auriga hydraulic disc brakes
180mm rotors front and rear, post-mount. Hydraulic self-adjusting — consistent stopping power fully loaded without manual pad adjustment. Motor inhibitors cut assist the moment you touch the lever for immediate response.
Commuter-ready from box — rack, lights, kickstand standard
Welded rear rack, Büchel 150-lumen front and rear LED lights, and heavy-duty adjustable kickstand all included. No accessories required to start commuting — assembly takes approximately 20 minutes.
Colours
White BlackPowertrain
| Motor | Bafang 500W (peaks 750W) Geared Hub Brushless |
| Torque | 65 Nm |
| Drive mode | Dropout torque-sensing pedal assist + thumb throttle |
| Throttle | Thumb push-activated |
| Controller | Surface 604 custom 12 MOS 48V 500W 25Ah Smart Controller |
| Top speed (PAS) | 45 km/h (28 mph) · Class 3 |
| Top speed (throttle) | 32 km/h (20 mph) |
Battery & Range
| Battery | 48V 20Ah / 960 Wh — Samsung lithium-ion 21700 cells |
| Battery weight | 4.65 kg / 10 lbs |
| Certification | UL 2271 (battery) + UL 2849 (complete system) |
| Range | Up to 150 km / 90 mi (eco mode) |
| Charge time | 3–4 hours (full charge from empty) |
Electronics
| Display | Surface 604 colour LCD, 3.5", with USB charging jack |
| Front light | Büchel "Secu Forte" LED — 150 lumens |
| Rear light | Büchel LED rear light |
| Wire harness | 30Ah rated, handles up to 120A (upgraded) |
Drivetrain
| Derailleur | Shimano Alivio 9-speed |
| Cassette | Shimano 11–36T |
| Shift levers | Shimano Alivio |
| Chain | KMC 9-speed |
| Crankset | Samox 42T front sprocket |
| Bottom bracket | Samox sealed |
Brakes
| Brakes | Tektro Auriga hydraulic disc — post mount, with motor inhibitors |
| Rotors | 180mm front and rear · 2.34mm thick |
Suspension
| Fork | SR Suntour XCM 27.5 · 80mm travel · quick release |
| Rear | Hardtail — no rear suspension |
Wheels & Tires
| Wheel size | 27.5" |
| Tires | 27.5" × 2.4" Panaracer · puncture protection · reflective sidewall |
| Rims | Aluminum alloy double-wall · 27.5" · 13G · 36H |
| Front hubs | Surface 604 aluminum |
Frame & Cockpit
| Frame | 6061 aluminum alloy · straight steerer headtube · custom reinforced battery mounts · internal cable routing · post-mount brakes |
| Stem | Satori Up2 adjustable |
| Handlebar | Promax aluminum · 30mm rise · 15° backsweep · 700mm wide |
| Pedals | Wellgo platform die-cast |
| Saddle | Selle Royal "Essenza Plus" gel · elastomer · relaxed position · 9° adjustable |
| Seat post | 30.4mm |
| Kickstand | Adjustable heavy-duty aluminum |
Sizing
| Sizes | S/M · M/L |
| Frame size (S/M) | 17.5" · for riders 5'2"–5'7" (158–170 cm) |
| Frame size (M/L) | 19.5" · for riders 5'8"–6'6" (173–198 cm) |
| Standover (S/M) | 28.5" / 724 mm |
| Standover (M/L) | 30" / 762 mm |
| Weight capacity | 136 kg / 300 lbs |
Weight & Features
| Net weight | 27.75 kg / 61 lbs (with 20Ah battery) |
| Standard accessories | Welded rear rack · adjustable kickstand · chain guide · water bottle bosses · fenders |
| Lights | Integrated front + rear (standard) |
| Optional upgrade | SR Suntour NCX suspension seatpost |
| Assembly time | ~20 minutes |
| Warranty | 5-year frame · 2-year components |
| Origin | Designed in Vancouver, Canada |
Surface 604 Colt · 48V 20Ah / 960 Wh · Bafang 500W · Shimano Alivio 9-Speed · 27.5" · S/M / M/L
