Tern - GSD S10 (Gen 3)

Tern GSD S10 Gen 3 – Smart, Safe, and Ready for Anything

Advanced Technology Meets Everyday Utility

The Tern GSD S10 Gen 3 is a cutting-edge electric cargo bike designed to handle heavy loads with ease while providing top-tier safety and connectivity features. Equipped with the Bosch Smart System, this bike offers a seamless blend of power, control, and intelligence, making it an ideal choice for families, businesses, and urban commuters.

Key Features

• Bosch Cargo Line Motor: Delivers up to 85 Nm of torque with 400% pedal assist, ensuring smooth acceleration even under heavy loads.

• Bosch Smart System: Integrates the Kiox 300 color display, providing ride customization, navigation, and theft protection features.

• Bosch Anti-Lock Braking System (ABS): Enhances braking safety by preventing wheel lock-up, especially in slippery conditions.

• Bosch Connect Module: Offers GPS tracking and an anti-theft alarm system, adding an extra layer of security.

• USB-C High Power Port: Allows for on-the-go charging of devices with a 10W output, ensuring your electronics stay powered during rides.

• Shimano Deore 10-Speed Drivetrain: Provides reliable and efficient gear shifting for various terrains.

• Magura MT-C 4-Piston Hydraulic Disc Brakes: Ensure strong and consistent stopping power, even under heavy loads.

• Adjustable Cockpit: Tool-free adjustable stem and seatpost accommodate riders from 150 to 200 cm (4'11" to 6'7"), making it ideal for shared family use.

• Robust Cargo Capacity: Rated for a maximum gross vehicle weight of 210 kg (463 lb), with the rear rack supporting up to 100 kg (220 lb), allowing for two child seats or substantial cargo.

• Compact Design: At 186 cm (73.2 inches) in length, it offers the convenience of a standard bicycle footprint, facilitating easy storage and navigation through tight urban spaces.

• Safety-Certified: Frame and fork are tested to meet the German DIN 79010 cargo bike safety standard, ensuring durability and rider confidence.

Specifications

• Frame: Tern GSD, 6061-AL, patented MultiTruss design, DIN 79010 certified

• Fork: Suntour custom for Tern, 1.5" tapered Chromoly steerer, 34 mm stanchions, Thru-axle, DIN 79010 certified

• Motor: Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)

• Battery: Bosch 545 PowerPack, Fast Swap, Dual Battery bays, optional 2 x 800 Wh max capacity

• Display: Bosch Kiox 300 w/ LED remote, connectivity with Bosch eBike Flow IOS/Smartphone app, electronic bike lock

• Range: 545 Wh: 45–98 km (28–61 mi); 1090 Wh: 90–196 km (56–122 mi)

• Drivetrain: Shimano Deore, 1 x 10 spd

• Rear Derailleur: Shimano Deore Shadow+

• Crankset: Tern GSD, forged 6061-AL DH crankarm

• Cassette: Shimano 11–42T, 10 spd

• Chain: KMC 10 spd, for eBike, EPT corrosion-resistant coating

• Brakes: Magura MT-C ABS, 4-piston hydraulic disc, 203 mm rotor

• Brake Levers: Magura MT-C e-stop, hydraulic, with brake light sensor

• Wheels: Tern Atlas, heavy-duty cargo wheels with ultra-wide 36 mm, dual reinforced joint rims

• Tires: Schwalbe Pick-Up, cargo-optimized, Super Defense puncture protection, Reflex

• Lighting: Front: Ignis Headlight, Hi/Lo beams, 700 lumens; Rear: RearStop Brake Light, Always on

• Fenders: Front: Aluminum; Rear: GSD wheel guard

• Kickstand: Atlas Lockstand Gen 2, AutoLock with remote unlock, patented technology

• Weight: Approximately 37.32 kg (82.3 lb)

Ideal For

• Family Transport: Safely carry up to two children with compatible child seats and accessories.

• Urban Commuting: Navigate city streets efficiently while carrying groceries, work gear, or other essentials.

• Eco-Friendly Lifestyle: Reduce reliance on cars for short to medium trips, contributing to a greener environment.

The Tern GSD S10 Gen 3 stands out as a practical solution for those seeking a reliable, versatile, and compact electric cargo bike. Its thoughtful design and robust features make it a valuable addition to any urban lifestyle.
