Quick Haul Long D9 · Gen 1 · 1×9 · Bosch Cargo Line
Quick Haul Long D9
Tern's most accessible electric cargo bike — carry two kids, a passenger, or a full load without breaking the bank.
The Quick Haul Long D9 is the entry point to Tern's cargo bike lineup — and it punches well above its price. Powered by the same Bosch Cargo Line motor found in the GSD (85 Nm, 400% assist), DIN 79010 certified for 190 kg gross vehicle weight, and built to carry two child passengers with plenty of heel clearance. A Tektro hydraulic disc brake system, 1×9-speed trigger shifter, and a robust Atlas kickstand make it a dependable, practical workhorse for family hauling without the premium price tag.
Highlights
Bosch Cargo Line motor — 85 Nm, 400% assist
The same flagship Bosch Cargo Line motor used in the GSD family. Tuned for heavy loads at lower speeds — flattens hills with two kids on board without breaking a sweat. Upgrade to the 500 Wh PowerPack for extended range — both sizes are interchangeable on legacy Bosch PowerPack bikes.
Designed to carry 2 kids with heel clearance
Compact cargo bike specifically engineered so riders have full heel clearance even with child seats installed on the rear rack — a thoughtful detail missing on many budget cargo bikes.
190 kg GVW — DIN 79010 certified
Frame and fork independently tested to the German DIN 79010 cargo bike safety standard, certified to 190 kg (419 lb) gross vehicle weight. Carry passengers and cargo with confidence.
Tektro hydraulic disc brakes
Front and rear hydraulic disc brakes deliver consistent, powerful stopping regardless of weather or load — a significant upgrade over mechanical disc brakes at this price point.
1×9-speed trigger shifter
Custom Tektro 1×9 drivetrain with 11–42T cassette and trigger shifter optimized for e-bike use. Fast, precise gear changes across a wide 23"–89" gear range.
Atlas Kickstand — cargo-rated stability
Tern's patented Atlas Kickstand is purpose-built for cargo bikes — keeps the bike rock steady while you load and unload passengers or cargo without it tipping.
90 kg Atlas L rear rack
Rated to 90 kg (198 lb) and compatible with Tern's range of Quick Haul Long accessories — child seats, cargo bags, and trays all mount directly.
Tool-free adjustable cockpit — fits 155–190 cm
Speedlifter adjustable stem lets you set handlebar height without tools to fit riders from 5'1" to 6'3". One bike, easy sharing between adults of different heights.
Tern×Schwalbe Super Moto-X tires
Custom co-developed tires with Green Guard puncture protection and Reflex reflective strip — built for durability under cargo loads with all-weather urban grip.
Available colours
E-System
| Motor | Bosch Cargo Line, 85 Nm, 400% assist |
| Battery system | Bosch PowerPack (legacy system) |
| Battery (equipped) | 400 Wh Bosch PowerPack |
| Battery (max single) | 500 Wh Bosch PowerPack (upgrade available) |
| Dual-battery | Not available |
| Range — 400 Wh | 42–85 km (26–53 mi) |
| Range — 500 Wh | ~53–106 km (est.) |
| Display | Bosch Purion, 4-mode, walk assist |
| Charger | 100–240V, 4A |
Drivetrain
| Shifter | Tektro, 1×9-speed, trigger |
| Rear derailleur | Tektro custom for Tern, 1×9-speed |
| Cassette | Tektro 11–42T, 9-speed |
| Crankset | Tern custom, forged 6061-AL, anti-drop chainring |
| Bottom bracket | Motor integrated |
| Chain | KMC for eBike, 9-speed |
| Gear range | 23"–89" (1.87–7.13 m) |
| Pedals | Urban, non-slip surface |
Brakes
| Front brake | Tektro hydraulic disc |
| Rear brake | Tektro hydraulic disc |
| Levers | Tektro hydraulic disc |
Wheels & Tires
| Rims | Tern Atlas H, cargo |
| Front hub | Disc, aluminium |
| Rear hub | 9-speed, disc, aluminium, Boost |
| Tires | Tern×Schwalbe Super Moto-X, Green Guard, Reflex |
| Spokes | Stainless steel |
Frame & Cockpit
| Frame | Tern Quick Haul Long, patented design, 6061-AL, DIN 79010 certified: 190 kg |
| Fork | Cargo aluminium alloy, DIN 79010 certified: 190 kg |
| Stem | Speedlifter, adjustable, 3D forged, 31.8mm |
| Handlebar | Low riser ergo, 31.8mm, 6061-AL |
| Headset | TH, cartridge bearings |
| Saddle | Velo Comfort |
| Seatpost | 34.9mm, 6061-AL, micro-adjust clamp |
| Grips | Velo ergonomic, lock-on |
Load & Capacity
| Max GVW | 190 kg (419 lb) |
| Max rider weight | 120 kg (265 lb) |
| Rack capacity | 90 kg (198 lb) |
| Rack | Atlas L, cargo |
| Kickstand | Atlas Kickstand, cargo-rated |
| Rider height range | 155–190 cm (5'1"–6'3") |
| Frame sizes | One size |
Dimensions
| Bike size | 187×70×102.5 cm (73.6×27.6×40.4 in) |
| Wheelbase | 130 cm (51.2 in) |
| Standover height | 48 cm (18.9 in) |
| Weight | 29.3 kg (64.6 lb) |
Extras
| Front light | 90 lux, StVZO approved |
| Rear light | Herrmans |
| Fenders | SplashGuard, stainless hardware |
| Chainguard | SKS Chainblade |
| Frame lock | ABUS or AXA, keyed-alike with Bosch battery |
| Luggage socket | Combo Mount |
| Bell | Aluminium |
Tern Quick Haul Long D9 · Gen 1 · One Size · Sunset / Mulberry / Ice Grey
- Description
Quick Haul Long D9 · Gen 1 · 1×9 · Bosch Cargo Line
Quick Haul Long D9
Tern's most accessible electric cargo bike — carry two kids, a passenger, or a full load without breaking the bank.
$5,399 CAD · Sale Price85 Nm motor torque 400 Wh equipped battery 190 kg max GVW 42–85 km (400 Wh equipped) ~53–106 km (500 Wh upgrade, est.) estimated range
The Quick Haul Long D9 is the entry point to Tern's cargo bike lineup — and it punches well above its price. Powered by the same Bosch Cargo Line motor found in the GSD (85 Nm, 400% assist), DIN 79010 certified for 190 kg gross vehicle weight, and built to carry two child passengers with plenty of heel clearance. A Tektro hydraulic disc brake system, 1×9-speed trigger shifter, and a robust Atlas kickstand make it a dependable, practical workhorse for family hauling without the premium price tag.
Highlights
Bosch Cargo Line motor — 85 Nm, 400% assist
The same flagship Bosch Cargo Line motor used in the GSD family. Tuned for heavy loads at lower speeds — flattens hills with two kids on board without breaking a sweat. Upgrade to the 500 Wh PowerPack for extended range — both sizes are interchangeable on legacy Bosch PowerPack bikes.
Designed to carry 2 kids with heel clearance
Compact cargo bike specifically engineered so riders have full heel clearance even with child seats installed on the rear rack — a thoughtful detail missing on many budget cargo bikes.
190 kg GVW — DIN 79010 certified
Frame and fork independently tested to the German DIN 79010 cargo bike safety standard, certified to 190 kg (419 lb) gross vehicle weight. Carry passengers and cargo with confidence.
Tektro hydraulic disc brakes
Front and rear hydraulic disc brakes deliver consistent, powerful stopping regardless of weather or load — a significant upgrade over mechanical disc brakes at this price point.
1×9-speed trigger shifter
Custom Tektro 1×9 drivetrain with 11–42T cassette and trigger shifter optimized for e-bike use. Fast, precise gear changes across a wide 23"–89" gear range.
Atlas Kickstand — cargo-rated stability
Tern's patented Atlas Kickstand is purpose-built for cargo bikes — keeps the bike rock steady while you load and unload passengers or cargo without it tipping.
90 kg Atlas L rear rack
Rated to 90 kg (198 lb) and compatible with Tern's range of Quick Haul Long accessories — child seats, cargo bags, and trays all mount directly.
Tool-free adjustable cockpit — fits 155–190 cm
Speedlifter adjustable stem lets you set handlebar height without tools to fit riders from 5'1" to 6'3". One bike, easy sharing between adults of different heights.
Tern×Schwalbe Super Moto-X tires
Custom co-developed tires with Green Guard puncture protection and Reflex reflective strip — built for durability under cargo loads with all-weather urban grip.
Available colours
Sunset Mulberry Ice GreyE-System
| Motor | Bosch Cargo Line, 85 Nm, 400% assist |
| Battery system | Bosch PowerPack (legacy system) |
| Battery (equipped) | 400 Wh Bosch PowerPack |
| Battery (max single) | 500 Wh Bosch PowerPack (upgrade available) |
| Dual-battery | Not available |
| Range — 400 Wh | 42–85 km (26–53 mi) |
| Range — 500 Wh | ~53–106 km (est.) |
| Display | Bosch Purion, 4-mode, walk assist |
| Charger | 100–240V, 4A |
Drivetrain
| Shifter | Tektro, 1×9-speed, trigger |
| Rear derailleur | Tektro custom for Tern, 1×9-speed |
| Cassette | Tektro 11–42T, 9-speed |
| Crankset | Tern custom, forged 6061-AL, anti-drop chainring |
| Bottom bracket | Motor integrated |
| Chain | KMC for eBike, 9-speed |
| Gear range | 23"–89" (1.87–7.13 m) |
| Pedals | Urban, non-slip surface |
Brakes
| Front brake | Tektro hydraulic disc |
| Rear brake | Tektro hydraulic disc |
| Levers | Tektro hydraulic disc |
Wheels & Tires
| Rims | Tern Atlas H, cargo |
| Front hub | Disc, aluminium |
| Rear hub | 9-speed, disc, aluminium, Boost |
| Tires | Tern×Schwalbe Super Moto-X, Green Guard, Reflex |
| Spokes | Stainless steel |
Frame & Cockpit
| Frame | Tern Quick Haul Long, patented design, 6061-AL, DIN 79010 certified: 190 kg |
| Fork | Cargo aluminium alloy, DIN 79010 certified: 190 kg |
| Stem | Speedlifter, adjustable, 3D forged, 31.8mm |
| Handlebar | Low riser ergo, 31.8mm, 6061-AL |
| Headset | TH, cartridge bearings |
| Saddle | Velo Comfort |
| Seatpost | 34.9mm, 6061-AL, micro-adjust clamp |
| Grips | Velo ergonomic, lock-on |
Load & Capacity
| Max GVW | 190 kg (419 lb) |
| Max rider weight | 120 kg (265 lb) |
| Rack capacity | 90 kg (198 lb) |
| Rack | Atlas L, cargo |
| Kickstand | Atlas Kickstand, cargo-rated |
| Rider height range | 155–190 cm (5'1"–6'3") |
| Frame sizes | One size |
Dimensions
| Bike size | 187×70×102.5 cm (73.6×27.6×40.4 in) |
| Wheelbase | 130 cm (51.2 in) |
| Standover height | 48 cm (18.9 in) |
| Weight | 29.3 kg (64.6 lb) |
Extras
| Front light | 90 lux, StVZO approved |
| Rear light | Herrmans |
| Fenders | SplashGuard, stainless hardware |
| Chainguard | SKS Chainblade |
| Frame lock | ABUS or AXA, keyed-alike with Bosch battery |
| Luggage socket | Combo Mount |
| Bell | Aluminium |
Tern Quick Haul Long D9 · Gen 1 · One Size · Sunset / Mulberry / Ice Grey
